Configurations
 |
 |
 |
Data Example
 |
Model No.
| WHEEL-01 | Running board with dynamo （ Pushed by hand ） |
| WHEEL-02 | Running board with dynamo （ Motor drive ） |
| RD76.5G-01 | 76GHz band radar |
| RD24.0GUWB-01 | 24GHz band UWB radar |
| 002090214-02 | Software |
HOME /
Radar & Radar Test Systems /
Radar Cross Section (RCS) Measurement and Evaluation System /
Approach type RCS measurement system
Approach type RCS measurement system
Approach Type RCS Measurement System
Model No. RAT08
Feature
The system sends and receives pulsed waves as it moves toward the target whose RCS you want to measure.
It measures the RCS , and fits it to the radar equation to obtain correct value.
Through making several measurements by changing the position of radar or target, you can see how the multipath on the road surface affects the results.
It is also possible to set up a fence in the middle to measure, avoiding multipath effects.
